Mark-10 MTT01-12 Torque Gauge 12-100 lbFin (135-1,150 Ncm) HighSpeed

Description

Product Overview

The Mark-10 MTT01-12 torque gauge is engineered for precise torque measurement in a wide range of industrial and scientific applications. Designed to cover a 12‑100 lbFin (135‑1,150 Ncm) spectrum, this instrument offers the flexibility needed for testing both low‑torque and high‑torque closures. Its high‑speed 7,000 Hz sampling rate captures rapid torque transients with exceptional accuracy, ensuring that peak torque values are recorded reliably even in fast‑acting processes. The gauge features an intuitive user interface with programmable set points, allowing operators to define pass/fail criteria that automatically trigger visual and audible alerts. Automatic data storage records each test result, and the device automatically zeros itself when the bottle cap is removed, reducing manual steps and minimizing the potential for human error. Constructed with a rugged aluminum housing, the MTT01‑12 meets the demanding durability standards of laboratory and production environments. Package dimensions measure 15.2 x 12.4 x 8.6 inches and the unit weighs 10.25 pounds, making it portable enough for field use while still providing a solid, stable platform for bench‑top testing. Manufactured by Mark‑10, a trusted name in torque measurement solutions, the gauge carries the model number MTT01‑12 and is listed under ASIN B008VFCKHM. It has earned a Best Sellers Rank of #38 in Torque Gauges, reflecting its popularity among professionals who require reliable, high‑performance torque testing equipment.

Usage

The MTT01‑12 excels in a variety of testing scenarios, from quality‑control labs that verify the integrity of tamper‑evident closures to manufacturing lines that need rapid, repeatable torque verification. Its programmable set points and automatic pass/fail determination make it ideal for batch testing, where dozens of units can be evaluated with minimal operator intervention. The high‑speed sampling capability is particularly valuable when testing fast‑acting closures, such as those found on beverage bottles, where the torque peak may occur within milliseconds. In addition to closure testing, the gauge can be employed for torque verification of mechanical fasteners, medical device components, and aerospace hardware, providing a versatile tool for engineers across multiple industries. The moveable posts and optional jaws included with the gauge accommodate a wide range of sample shapes and sizes, allowing users to secure irregularly shaped parts without compromising measurement accuracy. The device’s automatic zeroing feature activates as soon as the test specimen is removed, ensuring that each new measurement starts from a true baseline. This functionality, combined with the built‑in data storage, enables seamless integration with statistical process control (SPC) software, facilitating real‑time monitoring of production quality. The gauge’s compact footprint and lightweight design also make it suitable for portable field testing, where technicians can quickly assess torque compliance on‑site without the need for a full laboratory setup.

Why Choose Us

Choosing the Mark‑10 MTT01‑12 means partnering with a company that has over three decades of experience delivering torque measurement solutions that meet rigorous industry standards. Mark‑10’s commitment to precision engineering is reflected in the gauge’s robust construction, calibrated components, and extensive testing before shipment. Each unit undergoes a comprehensive quality‑assurance process that includes verification of sampling accuracy, verification of programmable set point functionality, and validation of data storage integrity. The result is a reliable instrument that consistently delivers repeatable results, reducing the need for costly recalibrations and downtime. In addition to product quality, Mark‑10 provides exceptional customer support, including a dedicated technical assistance line, online resources, and a network of authorized service centers. Customers benefit from rapid response times, detailed troubleshooting guides, and the option to purchase extended service contracts that cover preventive maintenance and calibration services. The MTT01‑12 also includes a comprehensive user manual that guides users through setup, operation, and data analysis, ensuring that both novice and experienced technicians can quickly become proficient with the device. By selecting this gauge, users gain access to a proven platform that integrates seamlessly with existing test rigs, software ecosystems, and data management workflows, delivering a total cost of ownership that is competitive in the torque measurement market.

Key Features

• Wide 12‑100 lbFin (135‑1,150 Ncm) range accommodates diverse testing needs, from delicate caps to heavy‑duty fasteners.
• 7,000 Hz high‑speed sampling captures rapid torque peaks, ensuring accurate measurement of fast‑acting closures.
• Automatic data storage and zeroing on cap removal streamline workflow and reduce manual errors.
• Programmable set point indicators provide clear pass/fail results, simplifying quality‑control decisions.
• Comprehensive after‑sales support, including technical assistance, calibration services, and extended warranty options.

FAQ

What torque range does the MTT01‑12 cover?

The gauge measures torque from 12 lbFin (135 Ncm) up to 100 lbFin (1,150 Ncm), providing flexibility for a broad spectrum of testing applications.

How does the automatic zeroing feature work?

When the test specimen, such as a bottle cap, is removed, the gauge detects the loss of load and automatically resets the baseline to zero, preparing the device for the next measurement without manual intervention.

Can the data be exported for analysis?

Yes, the built‑in data storage records each test result, and the information can be exported via USB or serial connection to standard spreadsheet or SPC software for further analysis.

Is the gauge compatible with existing test rigs?

The MTT01‑12 includes moveable posts and optional jaws that can be mounted on standard test rigs, making it easy to integrate into existing setups without extensive modifications.

What kind of support does Mark‑10 provide after purchase?

Mark‑10 offers a dedicated technical support line, online documentation, calibration services, and optional extended service contracts to ensure long‑term reliability and performance of the gauge.
